| BASIC INFORMATION |
| Rated Capacity |
|
|
| Cooling |
Btu |
24000 |
| Heating |
Btu |
– |
| Rated Running Current |
|
|
| Cooling |
A |
13.5 |
| Heating |
A |
– |
| Max. Input Power |
W |
2656 |
| Max. Input Current |
A |
15 |
| EER Cooling |
W/W |
3.11 |
| COP Heating |
W/W |
– |
| Power Supply Source |
V/Ph/Hz |
220～240V-1-50Hz |
| Refrigerant |
|
R410A |
| Refrigerant Charged |
g |
1400 |
| Max. Discharge Pressure |
Mpa |
4.3 |
| Max. Suction Pressure |
Mpa |
1.15 |
| Air Flow Volume |
m3/h |
1250 |
| Indoor Unit Noise Power |
dB(A) |
≤51 |
| Outdoor Unit Noise Power |
dB(A) |
≤61 |
| Indoor Unit Weight(Net) |
Kg |
14 |
| Outdoor Unit Weight(Net) |
|
60 |
| Container Loading 40HC |
Units |
150 |
| INDOOR UNIT |
| Evaporator |
|
|
| Bend |
|
7 |
| Evaporator Row |
|
2 |
| Evaporator Pipe Diameter |
mm |
Φ7×0.24 |
| Indoor Fan Motor |
|
D-310-50-8A |
| Dimension |
|
|
| Net Dimension |
mm |
1100×330×235 |
| Packing Dimension |
mm |
1180×400×317 |
| CONNECTION |
| Stop Valve |
|
|
| Liquid Valve |
mm |
Dg4 |
| Gas Valve |
mm |
Dg13 |
| OUTDOOR UNIT |
| Compressor Brand |
|
KK |
| Compressor Model |
|
AW5524B |
| Outdoor Fan Motor |
|
YDK69-6B |
| Condenser Pipe Diameter |
mm |
7.94 |
| Condenser Row |
|
2 |
| Dimension |
|
|
| Net Dimension |
mm |
825×655×310 |
| Packing Dimension |
mm |
945×725×435 |
