| BASIC INFORMATION |
| Rated Capacity |
|
|
| Cooling |
Btu |
3230 |
| Heating |
Btu |
3200 |
| Rated Running Current |
|
|
| Cooling |
A |
5.5 |
| Heating |
A |
4.5 |
| Max. Input Power |
W |
1600 |
| Max. Input Current |
A |
8.5 |
| EER Cooling |
W/W |
2.83 |
| COP Heating |
W/W |
3.37 |
| Power Supply Source |
V/Ph/Hz |
220-240V/1Ph/50Hz |
| Refrigerant |
|
R410A |
| Refrigerant Charged |
g |
700 |
| Max. Discharge Pressure |
Mpa |
4.3 |
| Max. Suction Pressure |
Mpa |
1.15 |
| Air Flow Volume |
m3/h |
600 |
| Indoor Unit Noise Power |
dB(A) |
42 |
| Outdoor Unit Noise Power |
dB(A) |
53 |
| Indoor Unit Weight(Net) |
Kg |
10 |
| Outdoor Unit Weight(Net) |
Kg |
28.5 |
| Container Loading 40HC |
Units |
240 |
| INDOOR UNIT |
| Evaporator |
|
|
| Bend |
|
3 |
| Evaporator Row |
|
2 |
| Evaporator Pipe Diameter |
mm |
7 |
| Indoor Fan Motor |
|
YYK18-4B |
| Dimension |
|
|
| Net Dimension |
mm |
881×296×205 |
| Packing Dimension |
mm |
977×370×285 |
| CONNECTION |
| Stop Valve |
|
|
| Liquid Valve |
mm |
Dg4 |
| Gas Valve |
mm |
Dg10 |
| OUTDOOR UNIT |
| Compressor Brand |
|
HIGHLY |
| Compressor Model |
|
ASG130 |
| Outdoor Fan Motor |
|
YDK30-6F |
| Condenser Pipe Diameter |
mm |
7 |
| Condenser Row |
|
1 |
| Dimension |
|
|
| Net Dimension |
mm |
730×545×285 |
| Packing Dimension |
mm |
850×370×620 |
