Product Specifications

Key Features
Gas type R410A
3D Air-Flow
Auto Restart
Golden Fin
Fast Cooling and Heating
Product Specification
Cooling (T1)
Capacity   Btu 18000
Current   A 7.2
EER   W/W 3.26
Cooling (T3)
Capacity   Btu 16000
Current   A 8.75
EER   W/W 2.38
Capacity   Btu 19500
Current   A 7.75
COP   W/W 3.3
Rated Power Input   W 3000
Rated Current   A 16
Max. Air Flow Volume   m3/h 745
Length of Pipe kit   m 3
Type   R410A
Charged   g 1400
Liquid piping   mm Φ6.35
Gas piping   mm Φ12.7
Max. Discharge Pressure   Mpa 4.8
Max. Suction Pressure   Mpa 1.5
Indoor Unit
Evaporator pipe Material   Copper
Evaporator bend   Yes
Evaporator row   2
Evaporator pipe diameter   mm 7
Fan Motor   YKFG-28-4-3-7
Max. Noise   dB(A) 43
Outdoor Unit
Compressor Brand   GMCC
Compressor Type   ROTARY
Compressor Model   PA205G2CS-4KTM1
Fan Motor   YKT-65-6-240L
Condenser Pipe Material   Copper
Condenser Row   1.6
Condenser Pipe Diameter   mm 7
Max. Noise   dB(A) 59
Power Supply
Voltage   V 220-240
Phase   Ph 1
Frequency   Hz 50
Product and Packaging Information
Indoor Unit
Product Dimension (WxHxD)   mm 965x215x319
Package Dimension (WxHxD)   mm 1045x305x405
Net wight   Kg 11.6
Gross wight   Kg 14.8
Outdoor Unit
Product Dimension (WxHxD)   mm 890x342x673
Package Dimension (WxHxD)   mm 995x398x740
Net wight   Kg 47.8
Gross wight   Kg 50.9
Shipping Information
Container Loading (20FT/40FT/40HQ)   Sets 62/132/144
Indoor CBM   m3 0.129083625
Outdoor CBM   m3 0.2930474
TTL CBM   m3 0.422131025
