SAT TV | 32”


High Definition, T2/S2

Product Specifications

Basic Information Media Format
Product Type LED TV Music MP3/AAC
Chassis 3MS463A0S2A Picture JPG、JPEG、BMP、PNG
OSD Language English/Persian/Arabian/French/
Video H.264、MPEG4、MPEG2、HEVC FHD、XVID、MKV w/o Divx
TV System PAL B/G、D/K、I    SECAM B/G、D/K
Channels(Analog) 99CH Signal Format Capability
DTV Channels(Digital) 3500CH (dynamic)
Power Supply AC 110V-240V  50/60Hz Component Video Format
Power Consumption(TV On) 55W, DVI Video Format
Power Consumption(Standby) ≤0.5W HDMI Video Format up to 1080P
Certification CB, HDMI, DD+
Basic Function Panel Specification
EPG Yes(at DTV) Backlight Unit LED
Subtitle Yes(at DTV) Panel supplier CSOT(ST3151A05-8/9)
Parental Control Yes(at DTV) Aspect Ratio 16:9
Lock Yes Panel Size (inch) 32″
Analog / Digital Signal Receiver Yes Display Resolution 1366*768
On/Off Timers Yes Brightness (cd/m2)(typ.) 220
Sleep Timer Yes Contrast Ratio 3000:1
Teletext Yes Response Time (G to G) 6.5ms
Nicam Yes Viewing Angle (H/V) 178°/178°
REC Yes(at DTV) Life Time(Typ.) >30,000hrs
Timeshift Yes(at DTV) Color 16.7 M(8bit)
System Update Yes Refresh Rate 60Hz
Hotel Mode Yes
Innovation Terminals
Smart Key(智能按键) Yes HDMI 2
Smart Source(智能信源) Yes USB 1
Soundbar Ready Yes AV in 1 mini
Enjoy Music Yes YPbPr 0
Headphone 1
Tuner ATV/DVB-T/C/T2/S2
CI 1, CI+
Picture Sound
DCC(Dynamic Contrast Control) NO Speakers Integrated speakers (Bottom side)
Backlight Adjustable Yes (0~100) Audio Power Output(THD=7%) 2×8W speaker box
Color Temperature Normal/Cold/Warm Smart Volume Yes(ON/OFF)
Picture Mode 4 picture effects preset (Standard, Dynamic,Mild, User) Smart Audio Music, Movie, Sports,Standard, User
Picture Size 16:9, 4:3, Zoom1, Zoom2 Sound Control Treble/Bass/Balance
DLTI Surround Sound NO
DCTI Sound Scene
Comb Filter 3D DD/DD+ (Dolby Digital ) Yes
Dynamic Noise Reduction 3D
Adaptive Deinterlacing 3D
Mechanical dimension
Mechanical Key Specification Remote ID Picture
Carton Dimensions LxWxH(mm) 800x128x520
Container Loading—20 feet(pcs) 520
Container Loading—40 feet(pcs) 1080
Container Loading–40 feet High(pcs) 1350
Net Weight With Stand(Kg) 4.2
Net Weight Without Stand(Kg) 4.2
Gross Weight With Packaging(Kg) 5.5
 VESA Mounting Dimensions LxH(mm) 100×100
Essential Accessories(Default) Optional Accessories
Operation Manual English(Default) Wall Mount WMB233
Remote Control and  batteries RC390 (with two batteries)
Base Stand Integrated Packaging
AC power cord Assenbled on TV
Adapt Cable Wire For AV Or YPBPR

Evolve for life.
